規格 | L | 500 | 1000 | 1500 | 2000 | 2500 | 3000 | 3500 | 4000 | 5000 | 5000 | 6000 | 6000 |
H | 60 | 60 | 60 | 100 | 100 | 100 | 100 | 150 | 150 | 175 | 150 | 175 | |
A | 30 | 30 | 30 | 40 | 40 | 40 | 40 | 80 | 80 | 80 | 80 | 80 | |
B | 6 | 6 | 6 | 8 | 8 | 8 | 8 | 10 | 10 | 10 | 10 | 10 | |
R | 4 | 4 | 4 | 6 | 6 | 6 | 6 | 8 | 8 | 10 | 8 | 10 | |
精度等級 | 0 | 0 | 1 | 1 | 1 | 2 | 2 | 2 | 3 | 2 | 3 | 2 | |
直線度 | 0.003 | 0.005 | 0.015 | 0.018 | 0.022 | 0.048 | 0.056 | 0.064 | 0.16 | 0.08 | 0.20 | 0.10 | |
平行度 | 0.004 | 0.008 | 0.022 | 0.027 | 0.033 | 0.072 | 0.084 | 0.13 | 0.24 | 0.12 | 0.30 | 0.15 | |
重量 | 0.8 | 1.5 | 2.3 | 6 | 7.5 | 9 | 10 | 28 | 35 | 40 | 42 | 50 | |
